Morse vs. harmonic bond potentials, and diatomic bond vibration

The harmonic bond potential (HarmonicBond) is the small-oscillation limit of the anharmonic Morse potential – they agree near the equilibrium separation but diverge away from it (Morse correctly flattens out toward a finite dissociation energy; harmonic does not). DiatomicOscillator integrates the classical two-body bond-vibration problem via the shared velocity-Verlet integrator, for either potential.

import matplotlib.pyplot as plt
import numpy as np

from chemistrykit.md.systems.pair_potentials import DiatomicOscillator, HarmonicBond, Morse

De, re = 4.0, 1.0
harmonic_k = 2.0 * De * 1.8**2  # match harmonic force constant to Morse's curvature at re (a=1.8)
morse = Morse(De=De, a=1.8, re=re)
harmonic = HarmonicBond(k=harmonic_k, r0=re)

r = np.linspace(0.7, 3.0, 400)

fig, axes = plt.subplots(1, 2, figsize=(11, 4.5))
axes[0].plot(r, morse.energy(r), label="Morse")
axes[0].plot(r, harmonic.energy(r), label="harmonic")
axes[0].axhline(-De, color="gray", linestyle=":", linewidth=0.8, label="dissociation limit (Morse)")
axes[0].set_xlabel("r")
axes[0].set_ylabel("U(r)")
axes[0].set_ylim(-De * 1.2, De * 1.5)
axes[0].set_title("Potential energy curves")
axes[0].legend()

<matplotlib.legend.Legend object at 0x11b1530e0>

Simulating the classical bond vibration for each potential, started stretched away from equilibrium: the harmonic bond oscillates forever with a fixed period; the (slightly softer, anharmonic) Morse bond oscillates at very nearly the same period for this small a displacement, since both potentials share the same curvature at re by construction.

m1 = m2 = 1.0
r0_displaced = 1.3
dt = 0.002
n_steps = 2000

for potential, label in [(harmonic, "harmonic"), (morse, "Morse")]:
    oscillator = DiatomicOscillator(potential, m1=m1, m2=m2, r0=r0_displaced)
    lengths = [oscillator.bond_length()]
    for _ in range(n_steps):
        oscillator.step(dt)
        lengths.append(oscillator.bond_length())
    axes[1].plot(np.arange(n_steps + 1) * dt, lengths, label=label)

period = DiatomicOscillator.harmonic_period(harmonic_k, m1, m2)
axes[1].axvline(period, color="gray", linestyle=":", linewidth=0.8, label="harmonic period")
axes[1].set_xlabel("t")
axes[1].set_ylabel("bond length r(t)")
axes[1].set_title("Classical bond-vibration trajectories")
axes[1].legend()
fig.tight_layout()

print(f"Harmonic vibration period: {period:.4f}")

plt.show()

Harmonic vibration period: 0.8727
