Grey radiative transfer: the Eddington approximation and limb darkening

The Sun’s disc is darker at the edge than at the centre. Looking toward the limb, the line of sight reaches optical depth one higher up, in cooler gas. Schwarzschild (1906) and Eddington (1926) explained this with the transfer equation for a plane-parallel atmosphere,

\[\mu\frac{dI}{d\tau} = I - S,\]

in radiative equilibrium with a grey (frequency-independent) opacity, so that \(S = J\) and the flux \(F = \sigma T_{\rm eff}^4\) is constant. The temperature is then \(T^4 = \tfrac34 T_{\rm eff}^4[\tau + q(\tau)]\). Eddington’s closure \(K = J/3\) gives \(q = 2/3\), so the surface sits at \(T = 2^{-1/4}T_{\rm eff}\) and \(T = T_{\rm eff}\) at \(\tau = 2/3\), with limb darkening

\[\frac{I(0, \mu)}{I(0, 1)} = \frac{2 + 3\mu}{5}.\]

The exact solution (Hopf 1930, Chandrasekhar 1944) has \(q\) rising from \(1/\sqrt3\) to \(0.7104\). This example computes it by Chandrasekhar’s discrete-ordinates method and compares both with the approximate linear limb darkening of the visible Sun.

import matplotlib.pyplot as plt
import numpy as np

from physicskit.astro.radiative_transfer import GreyAtmosphere, eddington_limb_darkening, eddington_temperature

atm = GreyAtmosphere(n_streams=32)
tau = np.geomspace(1e-3, 10.0, 400)
mu = np.linspace(0.0, 1.0, 201)

fig, axes = plt.subplots(1, 3, figsize=(15, 4))

The Hopf function

axes[0].semilogx(tau, atm.hopf(tau), color="crimson", label="exact grey (Hopf)")
axes[0].axhline(2 / 3, color="k", ls="--", label="Eddington, 2/3")
axes[0].axhline(1 / np.sqrt(3), color="gray", ls=":", lw=1)
axes[0].axhline(atm.Q, color="gray", ls=":", lw=1)
axes[0].text(1.5e-3, 1 / np.sqrt(3) + 0.003, r"$1/\sqrt{3}$", fontsize=8)
axes[0].text(1.5e-3, atm.Q + 0.003, f"{atm.Q:.4f}", fontsize=8)
axes[0].set_xlabel(r"optical depth $\tau$")
axes[0].set_ylabel(r"$q(\tau)$")
axes[0].set_title("Hopf function")
axes[0].legend(fontsize=8, loc="center right")

<matplotlib.legend.Legend object at 0x1305c8b30>

Temperature structure

axes[1].semilogx(tau, atm.temperature(tau), color="crimson", label="exact grey")
axes[1].semilogx(tau, eddington_temperature(tau), "k--", label="Eddington")
axes[1].axhline(1.0, color="gray", ls=":", lw=1)
axes[1].axvline(2 / 3, color="gray", ls=":", lw=1)
axes[1].set_xlabel(r"$\tau$")
axes[1].set_ylabel(r"$T / T_{\rm eff}$")
axes[1].set_title(r"$T = T_{\rm eff}$ near $\tau = 2/3$")
axes[1].legend(fontsize=8)

<matplotlib.legend.Legend object at 0x1305f4560>

Limb darkening

For comparison, the visible solar disc roughly follows the linear law I(mu)/I(1) = 1 - u(1 - mu) with u of about 0.6, close to Eddington’s u = 3/5; the real Sun is not grey, so its darkening varies with wavelength.

u_sun = 0.6
sun = 1 - u_sun * (1 - mu)
axes[2].plot(mu, atm.limb_darkening(mu), color="crimson", label="exact grey")
axes[2].plot(mu, eddington_limb_darkening(mu), "k--", label=r"Eddington $(2 + 3\mu)/5$")
axes[2].plot(mu, sun, color="goldenrod", ls=":", label=r"Sun, visible, $u \approx 0.6$")
axes[2].set_xlabel(r"$\mu = \cos\theta$ (1 at disc centre)")
axes[2].set_ylabel(r"$I(0, \mu)/I(0, 1)$")
axes[2].set_title("Limb darkening")
axes[2].legend(fontsize=8)
plt.tight_layout()
plt.show()

flux = 2 * np.trapezoid(atm.emergent_intensity(mu) * mu, mu)
print(f"q(0) = {float(atm.hopf(0.0)):.6f}, q(inf) = {atm.Q:.6f}")
print(f"limb/centre intensity: exact grey {float(atm.limb_darkening(0.0)):.4f}, Eddington 0.4000")
print(f"emergent flux / sigma T_eff^4 = {flux:.5f}")

q(0) = 0.577350, q(inf) = 0.710395
limb/centre intensity: exact grey 0.3439, Eddington 0.4000
emergent flux / sigma T_eff^4 = 0.99992

Check

assert abs(float(atm.hopf(0.0)) - 1 / np.sqrt(3)) < 1e-10
assert abs(atm.Q - 0.710446) < 1e-4
assert abs(float(atm.limb_darkening(0.0)) - 0.3439) < 1e-3
assert abs(flux - 1.0) < 1e-3
