The Deutsch-Jozsa algorithm: the first exponential quantum speed-up

David Deutsch (1985) asked whether a computer obeying quantum mechanics could do something no classical one can. With Richard Jozsa (1992) he gave the first problem with an exponential gap. A function \(f:\{0,1\}^n \to \{0,1\}\) is promised to be either constant or balanced (0 on exactly half the inputs). A deterministic classical algorithm may need \(2^{n-1} + 1\) evaluations to tell which. The quantum algorithm needs one call to the phase oracle \(|x\rangle \to (-1)^{f(x)}|x\rangle\):

\[\begin{split}H^{\otimes n}\,O_f\,H^{\otimes n}|0\rangle^{\otimes n}, \qquad P(0\dots0) = \Bigl|2^{-n}\sum_x(-1)^{f(x)}\Bigr|^2 = \begin{cases}1 & \text{constant} \\ 0 & \text{balanced.}\end{cases}\end{split}\]

The Hadamards query every input at once in superposition, and the interference at the output cancels the all-zero outcome exactly when \(f\) is balanced. This example runs the circuit for constant, balanced and unpromised functions, and counts the queries a classical algorithm needs.

import matplotlib.pyplot as plt
import numpy as np

from physicskit.quantum.chapters.quantum_circuits import QuantumCircuit, deutsch_jozsa_circuit

n = 4
N = 2**n
rng = np.random.default_rng(1)
functions = {
    "constant 0": np.zeros(N, int),
    "constant 1": np.ones(N, int),
    "balanced (parity)": np.array([bin(x).count("1") % 2 for x in range(N)]),
    "balanced (random)": rng.permutation(np.repeat([0, 1], N // 2)),
    "neither (3/4 ones)": rng.permutation(np.repeat([0, 1], [N // 4, 3 * N // 4])),
}

fig, axes = plt.subplots(1, 3, figsize=(15, 4))

One query decides

p_zero = {}
for i, (name, f) in enumerate(functions.items()):
    p = QuantumCircuit.probabilities(deutsch_jozsa_circuit(f).run(), n)
    p_zero[name] = p[0]
    axes[0].bar(np.arange(N) + 0.16 * (i - 2), p, width=0.16, label=name)
axes[0].set_xlabel("measured outcome x")
axes[0].set_ylabel("probability")
axes[0].set_title(f"Deutsch-Jozsa, n = {n}: outcome 0 iff f is constant")
axes[0].legend(fontsize=7)
for name, p0 in p_zero.items():
    print(f"{name:20s}: P(0000) = {p0:.4f}")

constant 0          : P(0000) = 1.0000
constant 1          : P(0000) = 1.0000
balanced (parity)   : P(0000) = 0.0000
balanced (random)   : P(0000) = 0.0000
neither (3/4 ones)  : P(0000) = 0.2500

Interference: amplitudes after the oracle

Between the two Hadamard layers every input carries amplitude (-1)^f(x)/sqrt(N); the last layer sums them into the 0 outcome.

qc = QuantumCircuit(n)
for q in range(n):
    qc.h(q)
qc.diagonal(np.pi * functions["balanced (random)"])
amps = qc.run().real * np.sqrt(N)
axes[1].bar(np.arange(N), amps, color=np.where(amps > 0, "steelblue", "crimson"))
axes[1].set_xlabel("input x")
axes[1].set_ylabel(r"$\sqrt{N}\,\langle x|O_f H^{\otimes n}|0\rangle$")
axes[1].set_title(r"Balanced: the $(-1)^{f(x)}$ phases sum to zero")

Text(0.5, 1.0, 'Balanced: the $(-1)^{f(x)}$ phases sum to zero')

Classical query counts

A deterministic algorithm must see more than half the truth table in the worst case, while the quantum circuit always makes one query.

ns = np.arange(1, 21)
axes[2].semilogy(ns, 2.0 ** (ns - 1) + 1, "o-", color="gray", label=r"classical worst case, $2^{n-1} + 1$")
axes[2].semilogy(ns, np.ones_like(ns), "o-", color="crimson", label="quantum, 1")
axes[2].set_xlabel("number of input bits n")
axes[2].set_ylabel("oracle queries")
axes[2].set_title("Exponential separation")
axes[2].legend()
plt.tight_layout()
plt.show()

Check

assert abs(p_zero["constant 0"] - 1) < 1e-12 and abs(p_zero["constant 1"] - 1) < 1e-12
assert p_zero["balanced (parity)"] < 1e-24 and p_zero["balanced (random)"] < 1e-24
assert abs(p_zero["neither (3/4 ones)"] - 0.25) < 1e-12  # |(4 - 12)/16|^2
assert deutsch_jozsa_circuit(functions["constant 0"]).gate_count()["D"] == 1
