Grover’s quantum search: a square-root speed-up

Lov Grover (1996) showed that finding a marked item among \(N\) unsorted ones takes about \(\tfrac{\pi}{4}\sqrt N\) queries of a quantum oracle, against \(N/2\) on average classically, and Bennett, Bernstein, Brassard and Vazirani had just proved that no quantum algorithm can do better. Each Grover iteration reflects the state about the unmarked subspace (the oracle) and then about the uniform superposition \(|s\rangle\) (the diffusion operator \(2|s\rangle\langle s| - I\)). Together they rotate it by \(2\theta\) toward the marked state, where \(\sin\theta = \sqrt{M/N}\), so after \(k\) iterations

\[P_{\text{success}} = \sin^2\bigl((2k + 1)\theta\bigr).\]

Iterating past the optimum rotates the state away again. This example follows the amplitudes through the iterations, checks the rotation formula, and measures the \(\sqrt N\) scaling.

import matplotlib.pyplot as plt
import numpy as np

from physicskit.quantum.chapters.quantum_circuits import grover_circuit, grover_optimal_iterations, grover_success_probability

fig, axes = plt.subplots(1, 3, figsize=(15, 4))

Amplitude amplification, n = 6 qubits, one marked item

n, marked = 6, 42
N = 2**n
k_opt = grover_optimal_iterations(N)
for k, color in [(0, "#c6dbef"), (2, "#6baed6"), (k_opt, "#08306b")]:
    psi = grover_circuit(n, [marked], iterations=k).run()
    axes[0].plot(np.arange(N), psi.real, ".-", ms=4, lw=0.5, color=color, label=f"{k} iterations")
axes[0].set_xlabel("basis state x")
axes[0].set_ylabel("amplitude")
axes[0].set_title(f"N = {N}, marked x = {marked}")
axes[0].legend(fontsize=8)

<matplotlib.legend.Legend object at 0x13117b0b0>

Success probability against the rotation formula

ks = np.arange(0, 3 * k_opt + 1)
p_sim = [abs(grover_circuit(n, [marked], iterations=k).run()[marked]) ** 2 for k in ks]
kf = np.linspace(0, ks[-1], 400)
axes[1].plot(kf, grover_success_probability(kf, N), "k-", lw=1, label=r"$\sin^2((2k+1)\theta)$")
axes[1].plot(ks, p_sim, "o", color="crimson", label="simulated")
axes[1].axvline(k_opt, color="gray", ls="--", lw=1)
axes[1].set_xlabel("Grover iterations k")
axes[1].set_ylabel("P(marked)")
axes[1].set_title(rf"Optimum at $k = \lfloor\pi/4\theta\rfloor = {k_opt}$")
axes[1].legend(fontsize=8)

<matplotlib.legend.Legend object at 0x1309cfe30>

Query scaling

n_values = np.arange(2, 13)
queries = np.array([grover_optimal_iterations(2**nn) for nn in n_values])
success = np.array([abs(grover_circuit(nn, [1], iterations=q).run()[1]) ** 2 for nn, q in zip(n_values, queries)])
axes[2].loglog(2.0**n_values, queries, "o", color="crimson", label="Grover iterations")
axes[2].loglog(2.0**n_values, np.pi / 4 * np.sqrt(2.0**n_values), "k-", lw=1, label=r"$\frac{\pi}{4}\sqrt{N}$")
axes[2].loglog(2.0**n_values, 2.0**n_values / 2, color="gray", ls="--", label="classical average, N/2")
axes[2].set_xlabel("N")
axes[2].set_ylabel("oracle queries")
axes[2].set_title("Square-root speed-up")
axes[2].legend(fontsize=8)
plt.tight_layout()
plt.show()
print("success probability at the optimum:", np.round(success, 4))

success probability at the optimum: [1.     0.9453 0.9613 0.9992 0.9966 0.9956 0.9999 0.9994 0.9995 1.
 0.9999]

Check

np.testing.assert_allclose(p_sim, grover_success_probability(ks, N), atol=1e-12)
assert np.all(success > 0.9) and success[-1] > 0.999
# floor(pi / 4 theta) is within one iteration of pi sqrt(N) / 4
assert np.all(np.abs(queries - np.pi / 4 * np.sqrt(2.0**n_values)) <= 1)
