Shor’s period finding and the quantum Fourier transform

Peter Shor (1994) showed that a quantum computer could factor integers in polynomial time, which no known classical algorithm does. Factoring \(N\) reduces to finding the period \(r\) of \(f(x) = a^x \bmod N\); then \(\gcd(a^{r/2} \pm 1, N)\) are factors. The quantum step is the Fourier transform over \(2^t\) amplitudes,

\[|x\rangle \to \frac{1}{\sqrt{2^t}}\sum_{y=0}^{2^t-1} e^{2\pi i xy/2^t}|y\rangle,\]

which Coppersmith (1994) built from just \(t(t+1)/2\) Hadamards and controlled phases, against \(O(t 2^t)\) operations for the classical FFT. Applied to \(\sum_x|x\rangle|a^x \bmod N\rangle\), it turns the period into sharp peaks at multiples of \(2^t/r\), which a continued fraction expansion reads off. This example checks the QFT circuit against the DFT matrix and factors \(15 = 3 \times 5\) with \(a = 7\).

import matplotlib.pyplot as plt
import numpy as np

from physicskit.quantum.chapters.quantum_circuits import (
    QuantumCircuit,
    modular_exponentiation_circuit,
    qft_circuit,
    shor_period_from_measurement,
)

fig, axes = plt.subplots(1, 3, figsize=(15, 4))

The QFT circuit is the discrete Fourier transform

n = 4
U = qft_circuit(n).unitary()
F = np.exp(2j * np.pi * np.outer(np.arange(2**n), np.arange(2**n)) / 2**n) / np.sqrt(2**n)
qft_error = np.abs(U - F).max()
axes[0].imshow(np.angle(U), cmap="twilight", interpolation="nearest")
axes[0].set_title(f"QFT on {n} qubits: phase of $U_{{yx}}$\n|U - DFT| = {qft_error:.1e}", fontsize=10)
axes[0].set_xlabel("input x")
axes[0].set_ylabel("output y")
ts = np.arange(2, 21)
axes[1].semilogy(ts, ts * (ts + 1) / 2, "o-", color="crimson", label=r"QFT gates, $t(t+1)/2$")
axes[1].semilogy(ts, ts * 2.0**ts, "o-", color="gray", label=r"classical FFT, $t\,2^t$")
axes[1].set_xlabel("qubits t")
axes[1].set_ylabel("operations")
axes[1].set_title("Fourier transform cost")
axes[1].legend()

<matplotlib.legend.Legend object at 0x13115e420>

Period finding for N = 15, a = 7

a, N, t = 7, 15, 8
qc, m = modular_exponentiation_circuit(a, N, t)
qc.append(qft_circuit(t).inverse())
p = QuantumCircuit.probabilities(qc.run(), t + m, tuple(range(t)))
axes[2].bar(np.arange(2**t), p, width=2.0, color="navy")
axes[2].set_xlabel("counting register y")
axes[2].set_ylabel("probability")
counts = QuantumCircuit.sample(p, shots=200, seed=0)
outcomes = np.nonzero(counts)[0]
periods = {int(y): shor_period_from_measurement(int(y), t, N) for y in outcomes}
r = max(periods.values())
factors = sorted({int(np.gcd(a ** (r // 2) - 1, N)), int(np.gcd(a ** (r // 2) + 1, N))})
axes[2].set_title(f"$7^x$ mod 15: peaks at multiples of $2^8/r$, r = {r}, 15 = {factors[0]} x {factors[1]}", fontsize=10)
plt.tight_layout()
plt.show()
print("measured y -> period candidate:", periods)
print(f"period r = {r}; gcd(7^{r // 2} -+ 1, 15) = {factors}")

measured y -> period candidate: {0: 1, 64: 4, 128: 2, 192: 4}
period r = 4; gcd(7^2 -+ 1, 15) = [3, 5]

Check

assert qft_error < 1e-12
np.testing.assert_array_equal(np.nonzero(p > 1e-9)[0], [0, 64, 128, 192])
assert r == 4 and pow(a, r, N) == 1 and factors == [3, 5]
