Durbin’s recursion for autoregressive fitting (1960)

The Yule-Walker equations have a Toeplitz matrix, and Norman Levinson (1947) had solved such systems, for Wiener’s filter, by a recursion on the order. James Durbin (1960) recast it for fitting autoregressions: the order-\(m\) model is the order-\((m-1)\) one plus a correction weighted by a reflection coefficient \(k_m\). It costs \(p^2\) operations instead of \(p^3\), gives every order on the way, so the prediction error can be watched as the order grows, and \(|k_m| < 1\) certifies a stable model (levinson_durbin()). Linear predictive coding of speech is built on it.

import matplotlib.pyplot as plt
import numpy as np
from scipy import linalg, signal

from engineeringkit.signal_processing import levinson_durbin

A fourth-order process

Two resonances. The biased sample autocorrelation of 20 000 samples feeds the recursion up to order 10.

poles = [0.95 * np.exp(1j * 0.6), 0.85 * np.exp(1j * 1.9)]
a_true = np.real(np.poly(poles + [p.conjugate() for p in poles]))
rng = np.random.default_rng(1960)
x = signal.lfilter([1.0], a_true, rng.normal(size=20000))
n = x.size
r = np.array([x[: n - k] @ x[k:] for k in range(11)]) / n
model = levinson_durbin(r, 10)

The recursion solves the Toeplitz system

direct = linalg.solve(linalg.toeplitz(r[:10]), -r[1:11])
assert np.allclose(model.coefficients[1:], direct)
print("order 4 from the recursion:", np.round(levinson_durbin(r, 4).coefficients, 3))
print("true:                      ", np.round(a_true, 3))

order 4 from the recursion: [ 1.    -1.023  0.761 -0.626  0.646]
true:                       [ 1.    -1.019  0.763 -0.637  0.652]

Prediction error against order

\(E_m = (1 - k_m^2)E_{m-1}\) falls until the true order and then stays flat, because the extra reflection coefficients are nearly zero.

k = model.reflection_coefficients
E = model.prediction_errors
fig, axes = plt.subplots(1, 3, figsize=(13, 3.6))
axes[0].plot(np.arange(11), E / E[0], "o-")
axes[0].axvline(4, color="0.6", ls="--")
axes[0].set(xlabel="order m", ylabel="$E_m/E_0$", yscale="log", title="Prediction error")
axes[1].stem(np.arange(1, 11), k, basefmt=" ")
axes[1].axhspan(-1, 1, color="0.95")
axes[1].set(xlabel="m", ylabel="$k_m$", ylim=(-1.1, 1.1), title="Reflection coefficients")
print("reflection coefficients:", np.round(k, 3))

reflection coefficients: [-0.716  0.528  0.06   0.646  0.009  0.006  0.002 -0.01  -0.006 -0.008]

Cost

The recursion takes about \(p^2\) multiplications, Gaussian elimination about \(p^3/3\).

orders = np.array([4, 16, 64, 256])
axes[2].loglog(orders, orders**2, "o-", label="Levinson-Durbin, p²")
axes[2].loglog(orders, orders**3 / 3, "s-", label="elimination, p³/3")
axes[2].set(xlabel="order p", ylabel="multiplications", title="Cost")
axes[2].legend(fontsize=8)
fig.tight_layout()
assert np.all(np.abs(k) < 1)
assert np.abs(k[4:]).max() < 0.03 and abs(E[4] / E[-1] - 1) < 0.01
assert np.allclose(levinson_durbin(r, 4).coefficients, a_true, atol=0.02)

plt.show()
